Sound Proof Canopy Acoustic Enclosure

Name: Sound Proof Canopy Acoustic Enclosure
Brand: JAIDEEP POWER SOLUTION PVT. LTD.
Price: 125000.0 INR
Availability: InStock

Price 125000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Sound Proof Canopy Acoustic Enclosure Specification

Dimension (L*W*H)
Variable by rating; Example: 2500mm x 1100mm x 1450mm Millimeter (mm)

Poles Number
4

Engine Model
Varies as per rating (Caterpillar / Cummins / Mahindra etc.)

Protection Class
IP23 / IP44

Bore *Stroke
100mm x 120mm (sample, varies by model)

Engine Type
Water Cooled, 4 Stroke Diesel Engine

Insulation
Class H

Fuel Tank Capacity
Standard 100 Litres (customizable as per requirement) Liter (L)

Product Type
Sound Proof Canopy Acoustic Enclosure for Generators

Output Type
AC Single/Three Phase

Rated Power
10 kVA to 625 kVA

Rated Voltage
415V / 230V Volt (V)

Starting Type
Electric Start

Rated Frequency
50 Hz Hertz (HZ)

Power Range
10 kVA to 625 kVA

Noise Level
Below 75 dB at 1 meter distance db

Color
Standard colors: Green, Blue, or as per client requirement

Weight
Varies by model, starting at 1000 Kg Kilograms (kg)

Material
Heavy duty CRCA sheet with powder coated finish

View Panel
Transparent Perspex window for monitoring control panel

Weather Resistance
Canopy is weather & corrosion resistant for outdoor installation

Locking System
Stainless steel locks and hinges

Sound Proof Canopy Acoustic Enclosure Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
01 Days

Main Domestic Market
Maharashtra

About Sound Proof Canopy Acoustic Enclosure

Feature

Greaves cotton dg sets range from 5 kva-12500 kva
Keycard makes servo voltage Stabilizers range from 1 kva - 2500 kva
Emerson vetiver ups range from 1 kva - 1000 kva
Keycard servo voltage stabilizers 5 kva - 5000 kva
Supernova Perkins dg sets ranges from 400 kva - 2250 kva

Superior Acoustic Insulation

With expertly designed baffles and high-grade insulation, the acoustic enclosure significantly reduces noise emissions, maintaining sound levels below 75 dB at a 1-meter distance. This makes it ideal for use in noise-sensitive environments while ensuring sufficient airflow and equipment cooling.

Robust & Weather-Resistant Construction

Manufactured from heavy duty CRCA sheet with a UV-stable epoxy polyester powder coating, the canopy provides formidable resistance against weather and corrosion. Additional features such as stainless steel hardware and rain guards maximize durability, making it suitable for outdoor installations across India.

User-Friendly Features & Customization

The enclosure includes a transparent Perspex view panel for real-time monitoring, provisions for fire extinguisher mounting, and lockable stainless steel hardware for security. Standard models accommodate 100-litre fuel tanks, but customization is available for different power ratings, dimensions, colors, and fuel capacities to align with specific project needs.

FAQs of Sound Proof Canopy Acoustic Enclosure:

Q: How does the canopy enclosure ensure effective noise reduction?

A: The acoustic enclosure integrates optimized baffle arrangements and specialized insulation materials (Class H) to minimize sound leakage, maintaining noise levels below 75 dB at a 1-meter distance. This design is suitable for locations where low noise output is crucial, such as hospitals or residential areas.

Q: What makes the sound proof canopy suitable for outdoor installations?

A: Featuring a heavy duty CRCA sheet structure with a durable epoxy polyester powder coating, the canopy resists weather, corrosion, and UV exposure. Additional rain guards and stainless steel hardware contribute to its lasting performance in diverse Indian climate conditions.

Q: When should fire safety provisions inside the canopy be considered?

A: Fire extinguisher mounting provisions are included as a safety feature and recommended for all installations, particularly in high-risk or remote locations, to support early fire suppression and enhance operator safety.

Q: Where can I monitor the equipment inside the enclosure without opening it?

A: A transparent Perspex view window is built into the enclosure, allowing direct visual access to the control panel and engine status without compromising the sound integrity or airflow of the system.

Q: What is the process for customizing the enclosure for specific requirements?

A: Customization options include adjusting dimensions, selecting from standard or client-specific colors, modifying fuel tank capacity, and matching the air handling arrangements. Consult with the manufacturer or supplier to define your requirements and receive a solution tailored to your project.

Q: How does the airflow system maintain equipment performance and cooling?

A: An optimized baffle system, along with louvered ventilation and rain guards, ensures adequate airflow. This maintains engine cooling and efficient operation while preventing water ingress, even in outdoor installations.

Q: What benefits does the powder-coated finish provide?

A: The epoxy polyester powder coating enhances the enclosures resistance to UV radiation, scratches, and corrosion, thereby prolonging the canopys lifespan and maintaining its visual appeal in challenging environmental conditions.
